Author: meba_admin

Meba-led heading lamp-KL2.5LM(B)

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba-led heading lamp-KL2.5LM(B)

Meba-led heading lamp-KL2.5LM(B)

Specification

Application:

Meba led heading lamp KL2.5LM(B) is suitable for mineral industry,tunnel projects,construction and maintenance for power, communication,highway,railway at night,night lamp for cutting off rubber plant and absorbing mucus and for lighting a flood,rescuing and marine use.

Battery (Nickel hydrogen)

Battery adpot high performance high-capacity enviromental battery,Part of battery has temperature device and over-current protection device ,top battery has short-circuit protection device.When miners lamp occured a short-circuit,it can cut off the power source within one millisecond 1ms and After the fault remove, the short-circuit device auto resume to normal working state.therefor it is very safe for miners.The cable has stretch-proof ,fire resistance function.The battery has IP54 waterproof class.

Charger:Nickel hydrogen

The charger is developed specialized for nickel hydrogen battery ,it adpot intelligent one core controller,it is improved lifetime and safety for battery.The charger light displays yellow when it gets electricity,it displays red when it is charging,it displays green when it is over-charging.If battery is over-discharging,it will use small battery to repair charging ,then it is going into normal charging .

Technical Data

No	Item		Unit	Data
1	Rated capacity		Ah	6
2	Nominal voltage		V	3.65
3	Lighting time		h	25
4	LEDlight source	Rated voltage	V	4.3
		Main light source/power	mA/W	250
		Auxiliary light source	mA	130
5	Max illuminance at 1m	Begin lighting	Lx	4500
5	Max illuminance at 1m	Lighting 11h	Lx	3000
6	Weight		g	750
7	Nos of battery cycle		times	500
8	Carton packing		roll/CNT	15
9	Packing size		cm	483729.5
10	With charger		pcs	1

Features

1. High quality

2. Popular in Chile, Peru, Colombia, Bolivia, Mexico, Kosovo, USA, UK, Turkey and so on

3. CE, EXSI, ISO certificates.

4. LED : less energy and super brightness LED

5. Battery : safety lithium ion battery

6. Small in size, light in weight, free maintenance, explosion prevention, waterproof, long life

7. Lighting time : more than 23h, double light source design

8. Charger AC input : AC110 ~ 240V, 50/60Hz DC output : DC4.2V,1A

9. Working temperature : -10 ~ 45 degrees

10. Relative air humidity : <= 95% +- 3RH

Gallery

Meba-led heading lamp-KL2.5LM(B)

Online Catalogue

[Download not found]

LED Mining Light

Meba-led mining headlight-KJ6LM(A)

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba-led mining headlight-KJ6LM(A)

Meba-led mining headlight-KJ6LM(A)

Specification

Application:

Meba led mining headlight KJ6LM(A) is suitable for mineral industry,tunnel projects,construction and maintenance for power, communication,highway,railway at night,night lamp for cutting off rubber plant and absorbing mucus and for lighting a flood,rescuing and marine use.

Battery (Nickel hydrogen)

Charger:Nickel hydrogen

Technical Data

No	Item		Unit	Data
1	Rated capacity		Ah	6
2	Nominal voltage		V	3.65
3	Lighting time		h	25
4	LEDlight source	Rated voltage	V	4.3
		Main light source/power	mA/W	250
		Auxiliary light source	mA	130
5	Max illuminance at 1m	Begin lighting	Lx	4500
5	Max illuminance at 1m	Lighting 11h	Lx	3000
6	Weight		g	750
7	Nos of battery cycle		times	500
8	Carton packing		roll/CNT	15
9	Packing size		cm	483729.5
10	With charger		pcs	1

Features

1. High quality

2. Popular in Chile, Peru, Colombia, Bolivia, Mexico, Kosovo, USA, UK, Turkey and so on

3. CE, EXSI, ISO certificates.

4. LED : less energy and super brightness LED

5. Battery : safety lithium ion battery

6. Small in size, light in weight, free maintenance, explosion prevention, waterproof, long life

7. Lighting time : more than 23h, double light source design

8. Charger AC input : AC110 ~ 240V, 50/60Hz DC output : DC4.2V,1A

9. Working temperature : -10 ~ 45 degrees

10. Relative air humidity : <= 95% +- 3RH

Gallery

Meba-led mining headlight-KJ6LM(A)

Online Catalogue

[Download not found]

LED Mining Light

Meba-led mining lamp-KJ3.5LM(A)

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba-led mining lamp-KJ3.5LM(A)

Meba-led mining lamp-KJ3.5LM(A)

Specification

Application:

Meba led mining lamp KJ3.5LM(A) is suitable for mineral industry,tunnel projects,construction and maintenance for power, communication,highway,railway at night,night lamp for cutting off rubber plant and absorbing mucus and for lighting a flood,rescuing and marine use.

Battery (Nickel hydrogen)

Charger:Nickel hydrogen

Technical Data

No	Item		Unit	Data
1	Rated capacity		Ah	6
2	Nominal voltage		V	3.65
3	Lighting time		h	25
4	LEDlight source	Rated voltage	V	4.3
		Main light source/power	mA/W	250
		Auxiliary light source	mA	130
5	Max illuminance at 1m	Begin lighting	Lx	4500
5	Max illuminance at 1m	Lighting 11h	Lx	3000
6	Weight		g	750
7	Nos of battery cycle		times	500
8	Carton packing		roll/CNT	15
9	Packing size		cm	483729.5
10	With charger		pcs	1

Features

1. High quality

2. Popular in Chile, Peru, Colombia, Bolivia, Mexico, Kosovo, USA, UK, Turkey and so on

3. CE, EXSI, ISO certificates.

4. LED : less energy and super brightness LED

5. Battery : safety lithium ion battery

6. Small in size, light in weight, free maintenance, explosion prevention, waterproof, long life

7. Lighting time : more than 23h, double light source design

8. Charger AC input : AC110 ~ 240V, 50/60Hz DC output : DC4.2V,1A

9. Working temperature : -10 ~ 45 degrees

10. Relative air humidity : <= 95% +- 3RH

Gallery

Meba-led mining lamp-KJ3.5LM(A)

Online Catalogue

[Download not found]

LED Mining Light

Meba-led mining light product-KJ4.5LM(A)

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba-led mining light product-KJ4.5LM(A)

Meba-led mining light product-KJ4.5LM(A)

Specification

Application:

Meba led mining light product KJ4.5LM(A) is suitable for mineral industry,tunnel projects,construction and maintenance for power, communication,highway,railway at night,night lamp for cutting off rubber plant and absorbing mucus and for lighting a flood,rescuing and marine use.

Battery (Nickel hydrogen)

Charger:Nickel hydrogen

Technical Data

No	Item		Unit	Data
1	Rated capacity		Ah	6
2	Nominal voltage		V	3.65
3	Lighting time		h	25
4	LEDlight source	Rated voltage	V	4.3
		Main light source/power	mA/W	250
		Auxiliary light source	mA	130
5	Max illuminance at 1m	Begin lighting	Lx	4500
5	Max illuminance at 1m	Lighting 11h	Lx	3000
6	Weight		g	750
7	Nos of battery cycle		times	500
8	Carton packing		roll/CNT	15
9	Packing size		cm	483729.5
10	With charger		pcs	1

Features

1. High quality

2. Popular in Chile, Peru, Colombia, Bolivia, Mexico, Kosovo, USA, UK, Turkey and so on

3. CE, EXSI, ISO certificates.

4. LED : less energy and super brightness LED

5. Battery : safety lithium ion battery

6. Small in size, light in weight, free maintenance, explosion prevention, waterproof, long life

7. Lighting time : more than 23h, double light source design

8. Charger AC input : AC110 ~ 240V, 50/60Hz DC output : DC4.2V,1A

9. Working temperature : -10 ~ 45 degrees

10. Relative air humidity : <= 95% +- 3RH

Gallery

Meba-led mining light product-KJ4.5LM(A)

Online Catalogue

[Download not found]

Miniature Circuit Breaker

Meba mcb type C MB1236C

Meba mcb type C MB1236C

Specification

Meba mcb type c MB1236C adopts advanced design technology, it has protective function as shortage as overload, and are used in lighting distribution system industry, commerce and dwelling, and protecting fractional electric motors, and they also have many merits of high protective grade(up to IP20), high breaking capacity, reliable sensitive action, convenient, multiple assembling, long life etc. Meba mcb type c MB1236C are mainly adapted to the circuit of AC 50Hz, 230V in single pole; 400V in double, three, four poles for protecting overload and short circuit, meanwhile Meba mcb type c MB1236C are also used in turning on or off the electric apparatus and lighting circuit under the normal condition.

Technical Parameter

	IEC 60898 IEC60947
Tropicalization	Relative Humidity	℃	93% RH at 25℃
Tropicalization	Room Temperature	℃	-5℃ a 40℃
Electrical Properties	Rated at 40℃	A	6/10/16/20/25/32/40/50/63
	Rated operating voltage at 40℃	Vac	240/415
	Nominal Frequency	Hz	50/60
	Interrupting Capacity at 230V	kA	6
	Operating temperature	℃	-5℃ a 40℃
	Degree of Protection		IP20
	Number of poles		1/2/3/4
	Conductor cross section (minimum allowable)	mm²	25
	Minimum number of power moves		6000
	Minimum number of mechanical operations		20000
	Operation curve		B/C/D
	Current Trip Curve	A	5 a 10 In
	Characteristic Intervention		attach
Type Of Assembly	FOR RIEL DIN 35 mm
Operation Indicator Window	The circuit breaker have an operating window color display that shows the state in which it is (connected or disconnected).
Features	MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 3 to 5 times rated current (Type B), 10 to 14 times rated current (Type D)
	BIMETAL: ensures the breaker trip when overloaded.
	ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.
Present Certificates	CE CB
	ISO 9001-2000 awarded by the competent certification body, Meba is qualified in the manufacturing of the object
	IEC 60898 standards in the manufacture of the goods
	Curve compliance issued Shot by an accredited laboratory for effect
	Life, given by Meba to ensure that the life of the goods offered by at least 15 years.
Testing For Acceptance	Before receiving the circuit breakers(breakers), customers may perform the tests may be necessary to ensure compliance with the technical specifications.
Packing	The packaging is sure that withstand any adverse conditions during transport and handling to the warehouse of cutomers.
Dial Century, Year, Month and Batch	In one of its sides the breaker is marked with permanent ink, year, month and batch.
Catalog	Attach catalogs indicating the technical specification
Shows	Submit sample of the product offered
Technical Warranty	2 YEARS
Place of Delivery	CNF&FOB
Delivery	25 DAYS

Gallery

Meba mcb type C MB1236C

PDF Download

[Download not found]

Tags MCB, mcb type c, Mini Circuit Breaker

Explosion-proof Light

Meba-explosion proof floodlight-BC91

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba-explosion proof floodlight-BC91

Meba-explosion proof floodlight-BC91

Specification

General:

Meba explosion proof floodlight BC91 is a light which applies LED technology, a kind of application without making any noise. With good protection Ni-Cd battery, its using life can be extended till a long time. Energy-saving and highly-qualified.

Application:

1) Building (architecture or home) decoration.
2) Car decoration
3) Amusement park and theater lighting
4) Emergency hallway lighting
5) Shopping mall, restaurant, hotel, meeting room and advertisement signs backlighting

Features

1)Full fire-resistant Material, constant current charge
2)Over-charge and over discharge protected
3)Long-life non-corrosive Ni-CD battery
4)Easy to be maintained, convenient to operate, safe and reliable
5)Designed according to Chinese GB17945-2000 standard, CE standard
6)Widely used in modern hotels, shops and other public places, security evacuation and guide
7)Power supply: AC 110V/220V, 50/60Hz
8)Switching time: <0.25S
9)Recharging time: <24 hours
10)Illumination time: >90 minutes (or design according to the client’s need )
11)Light source: LED
12)Sight distance: 20m
13)Installing stype: Wall-hanging mount
14)Various designs available

Gallery

Meba-explosion proof floodlight-BC91

Online Catalogue

[Download not found]

Explosion-proof Light

Meba-explosion proof emergent sign light-BBD4200

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba-explosion proof emergent sign light-BBD4200

Meba-explosion proof emergent sign light-BBD4200

Specification

General

Meba explosion proof emergent sign light BBD4200 is a light which applies LED technology, a kind of application without making any noise. With good protection Ni-Cd battery, its using life can be extended till a long time. Energy-saving and highly-qualified.

Application:

Features

Gallery

Meba-explosion proof emergent sign light-BBD4200

Online Catalogue

[Download not found]

Miniature Circuit Breaker

Meba type a mcb MBD2

Meba type a mcb MBD2

Specification

Meba type a mcb MBD2 , major export to South America, Middle East market, has light weight, small size, novel structure and excellent performance. They are mounted in the metal distribution board and used in guesthouses. block of fiats, high buildings, squares, airports, railway stations, plants and enterprises etc, in AC circuits 240V(single pole)up to 415V(3poie)50Hz for protection of overload short circuit and for circuit changeover in lighting system. Breaking capacity is 3KA. The items comply with BS & NEMA STANDARD.

Technical Parameter

Tropicalization	Relative Humidity	℃	93% RH at 25 ℃
Tropicalization	Room Temperature	℃	10 ℃ a 60 ℃
Electrical Properties	Rated at 40 ℃	A	6/10/15/20/30/40/50/60
	Rated operating voltage at 40 ℃	Vac	120/240/415
	Nominal Frequency	Hz	50/60
	Interrupting Capacity at 230V	kA	3
	Operating temperature	℃	-5 ℃ a +40 ℃
	Degree of Protection		IP20
	Number of poles		1,2,3,4
	Conductor cross section (minimum allowable)	mm²	25
	Minimum number of power moves		4000
	Minimum number of mechanical operations		6000
	Operation curve		B/C/D
	Current Trip Curve	A	Type B 3a 5 In Type C 5 a 10 In Type D 10 a 14 In
	Characteristic Intervention		attach
Type Of Assembly	NEMA Type
Features	MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 10 to 14 times rated current ( Type D )
	BIMETAL: ensures the breaker trip when overloaded.
	ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Gallery

Meba type a mcb MBD2

PDF Download

Tags type a mcb

Miniature Circuit Breaker

Miniature tripped circuit breaker SDM61

Post author By meba_admin
Post date 13/12/2013
No Comments on Miniature tripped circuit breaker SDM61

Miniature tripped circuit breaker SDM61

Specification

Application:

Meba mem mcb major export to South America, Middle East market, has light weight, small size, novel structure and excellent performance. They are mounted in the metal distribution board and used in guesthouses. block of fiats, high buildings, squares, airports, railway stations, plants and enterprises etc, in AC circuits 240V(single pole)up to 415V(3poie)50Hz for protection of overload short circuit and for circuit changeover in lighting system. Breaking capacity is 3KA. The items comply with BS&NEMA STANDARD.

Technical Data

ropicalization	Relative Humidity	℃	93% RH at 25℃
ropicalization	Room Temperature	℃	10℃ a 60℃
Electrical Properties	Rated at 40℃	A	6/10/15/20/30/40/50/63
	Rated operating voltage at 40℃	Vac	120/240/415
	Nominal Frequency	Hz	50/60
	Interrupting Capacity at 230V	kA	3
	Operating temperature	℃	-5℃ a +40℃
	Degree of Protection		IP20
	Number of poles		1,2,3,4
	Conductor cross section (minimum allowable)	mm²	25
	Minimum number of power moves		4000
	Minimum number of mechanical operations		6000
	Operation curve		B/C/D
	Current Trip Curve	A	Type B 3a 5 In Type C 5 a 10 In Type D 10 a 14 In
	Characteristic Intervention		attach
Type Of Assembly	NEMA Type
Features	MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 10 to 14 times rated current ( Type D )
	BIMETAL: ensure the breaker trip when overloaded.
	ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Features

MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 3 to 5 times rated current ( Type B ), 10 to 20 times rated current ( Type D )

BIMETAL: ensures the breaker trip when overloaded.

ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Gallery

Miniature tripped circuit breaker SDM61

PDF Download

Tags Circuit breaker

Miniature Circuit Breaker

Meba Miniature tripped circuit breaker SDM61

Post author By meba_admin
Post date 12/12/2013
No Comments on Meba Miniature tripped circuit breaker SDM61

Meba Miniature tripped circuit breaker SDM61

Specification

Application:

Meba Miniature tripped circuit breaker SDM61 major export to South America, Middle East market, has light weight, small size, novel structure and excellent performance. They are mounted in the metal distribution board and used in guesthouses. block of fiats, high buildings, squares, airports, railway stations, plants and enterprises etc, in AC circuits 240V(single pole)up to 415V(3poie)50Hz for protection of overload short circuit and for circuit changeover in lighting system. Breaking capacity is 3KA. The items comply with BS&NEMA STANDARD.

Technical Data

ropicalization	Relative Humidity	℃	93% RH at 25℃
ropicalization	Room Temperature	℃	10℃ a 60℃
Electrical Properties	Rated at 40℃	A	6/10/15/20/30/40/50/63
	Rated operating voltage at 40℃	Vac	120/240/415
	Nominal Frequency	Hz	50/60
	Interrupting Capacity at 230V	kA	3
	Operating temperature	℃	-5℃ a +40℃
	Degree of Protection		IP20
	Number of poles		1,2,3,4
	Conductor cross section (minimum allowable)	mm²	25
	Minimum number of power moves		4000
	Minimum number of mechanical operations		6000
	Operation curve		B/C/D
	Current Trip Curve	A	Type B 3a 5 In Type C 5 a 10 In Type D 10 a 14 In
	Characteristic Intervention		attach
Type Of Assembly	NEMA Type
Features	MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 10 to 14 times rated current ( Type D )
	BIMETAL: ensure the breaker trip when overloaded.
	ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Features

BIMETAL: ensures the breaker trip when overloaded.

ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Gallery

Meba Miniature tripped circuit breaker SDM61

PDF Download

Tags breaker, Circuit breaker, MCB

Miniature Circuit Breaker

Meba mem mcb

Meba mem mcb

Specification

Application:

Technical Data

ropicalization	Relative Humidity	℃	93% RH at 25℃
ropicalization	Room Temperature	℃	10℃ a 60℃
Electrical Properties	Rated at 40℃	A	6/10/15/20/30/40/50/63
	Rated operating voltage at 40℃	Vac	120/240/415
	Nominal Frequency	Hz	50/60
	Interrupting Capacity at 230V	kA	3
	Operating temperature	℃	-5℃ a +40℃
	Degree of Protection		IP20
	Number of poles		1,2,3,4
	Conductor cross section (minimum allowable)	mm²	25
	Minimum number of power moves		4000
	Minimum number of mechanical operations		6000
	Operation curve		B/C/D
	Current Trip Curve	A	Type B 3a 5 In Type C 5 a 10 In Type D 10 a 14 In
	Characteristic Intervention		attach
Type Of Assembly	NEMA Type
Features	MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 10 to 14 times rated current ( Type D )
	BIMETAL: ensure the breaker trip when overloaded.
	ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Features

BIMETAL: ensures the breaker trip when overloaded.

ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Gallery

Meba mem mcb

PDF Download

Miniature Circuit Breaker

Meba THQP ge circuit breakers

Post author By meba_admin
Post date 18/12/2013
No Comments on Meba THQP ge circuit breakers

Meba THQP ge circuit breakers

Specification

Application:

Meba THQP ge circuit breakers is used in lighting distribution system or motor distribution system for protection overload and short-circuit in the system. The product is neoteric in structure, light in weight, reliable and excellent in performance. It has high breaking capacity, can trip quickly, and its case and items are adopted by high fire-resistant and shockproof plastics. The product, with long life, is mainly used in AC 50Hz/60Hz single-pole 230V or two, three, four pole 400V circuit for overload and short-circuit protection as well as for unfrequent on-and-off switching electric equipment and lighting circuit in normal case. The products comply with IEC 60898.

Technical Data

Pole number	Rated current(A)	Rated voltage(V)	Rated making and breaking capacity(KA)		Setting temperature of protective characteristics
			B.S	NEMA
1P	6, 10, 15, 20, 30, 40, 50, 63	AC12		5	40
		AC120/230		5
		AC230/400	3
2P	6, 10, 15, 20, 30, 40	AC120/230			40
		AC230/400	3	5
3P	50, 63	AC230/400	3

Connection
Pillar type terminal
Mounting: clips pan assembly base
Plug-in mounting base

Overall & Installation Dimensions

Gallery

Meba THQP ge circuit breakers

PDF Download

Tags ge circuit breaker

U Type AC Automatic Voltage Regulator

Meba Power Regulator SVC-U500VA

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba Power Regulator SVC-U500VA

Meba Power Regulator SVC-U500VA

Specification

General:

SVC-U series single-phase voltage regulators not only bear all the characteristics of SVC but also have advantages of luxurious appearance and strong protection functions.

Application:

For office equipment, testing equipment, medical equipment, industrial automation equipment, household appliance, lighting system, communication system, etc. Provide kinds of electrical appliances with abundant electric power meeting different requirements.

Technical Data

lnput voltage	150V~250V
Output voltage	220V or 110V
Accuracy of voltage stabilization	220V±3% 110V±6%
Frequency	50Hz/60Hz
Adjusting time	＜1s (when input voltage has a change of 10%)
Efficiency	＞90%
Over-voltage protection	246V±4V
Ambient temperature	-5℃～+40℃
Relative humidity	≤90%
Waveform distoriton	No additional waveform distortion
Load power factor	0.8
Dielectric strength	1500/min
lnsulation resistance	≥2MΩ

Gallery

Meba Power Regulator SVC-U500VA

PDF Download

Tags Automatic Voltage Regulator, Power Regulator

U Type AC Automatic Voltage Regulator

Meba Strong Automatic Voltage Regulators SVC-U1500VA

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba Strong Automatic Voltage Regulators SVC-U1500VA

Meba Strong Automatic Voltage Regulators SVC-U1500VA

Specification

General:

SVC-U series single-phase voltage regulators not only bear all the characteristics of SVC but also have advantages of luxurious appearance and strong protection functions.

Application:

Performance:

lnput voltage	150V~250V
Output voltage	220V or 110V
Accuracy of voltage stabilization	220V±3% 110V±6%
Frequency	50Hz/60Hz
Adjusting time	＜1s (when input voltage has a change of 10%)
Efficiency	＞90%
Over-voltage protection	246V±4V
Ambient temperature	-5℃～+40℃
Relative humidity	≤90%
Waveform distoriton	No additional waveform distortion
Load power factor	0.8
Dielectric strength	1500/min
lnsulation resistance	≥2MΩ

Gallery

Meba Strong Automatic Voltage Regulators SVC-U1500VA

PDF Download

[Download not found] SVC-U1.5KVA Strong Automatic Voltage Regulators suit for office equipment, test equipment, medical equipment, industrial automation equipment, household lighting system, communication system, etc.

Tags Automatic Voltage Regulator, Power Regulator

Miniature Circuit Breaker

Meba mcb breaker MABD

Meba mcb breaker MABD

Specification

Application:

Meba mcb breaker MABD is used in lighting distribution system or motor distribution system for protection overload and short-circuit in the system. The product is neoteric in structure, light in weight, reliable and excellent in performance. It has high breaking capacity, can trip quickly, and its case and items are adopted by high fire-resistant and shockproof plastics. The product, with long life, is mainly used in AC 50Hz/60Hz single-pole 230V or two, three, four pole 400V circuit for overload and short-circuit protection as well as for unfrequent on-and-off switching electric equipment and lighting circuit in normal case. The products comply with IEC 60898.

Technical Parameter

Tropicalization	Relative Humidity	℃	93% RH at 25℃ 50% RH at 40℃
Tropicalization	Room Temperature	℃	-5℃ a 40℃
Electrical Properties	Rated at 40℃	A	6/10/16/20/25/32/40/50/63
	Rated operating voltage at 40℃	Vac	240/415
	Nominal Frequency	Hz	50/60
	Interrupting Capacity at 230V	kA	6
	Operating temperature	℃	-5℃a 40℃
	Degree of Protection		IP20
	Number of poles		1/2/3/4
	Conductor cross section (minimum allowable)	mm²	25
	Minimum number of power moves		4000
	Minimum number of mechanical operations		8000
	Operation curve		B/C/D
	Current Trip Curve	A	Type B: 3 a 5 In Type C: 5 a 10 In Type D: 10 a 14 In
	Characteristic Intervention		attach
Type Of Assembly	FOR RIEL DIN 35mm
Features	MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 3 to 5 times rated current ( Type B ), 10 to 14 times rated current ( Type D )
	BIMETAL: ensures the breaker trip when overloaded.
	ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Gallery

Meba mcb breaker MABD

PDF Download

Tags electrical breaker, MCB Breaker

U Type AC Automatic Voltage Regulator

Meba Tested Automatic Voltage Regulator SVC-U1000VA

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba Tested Automatic Voltage Regulator SVC-U1000VA

Meba Tested Automatic Voltage Regulator SVC-U1000VA

Specification

General:

SVC-U series single-phase voltage regulators not only bear all the characteristics of SVC but also have advantages of luxurious appearance and strong protection functions.

Application:

Technical Parameter

Performance:

lnput voltage	150V~250V
Output voltage	220V or 110V
Accuracy of voltage stabilization	220V±3% 110V±6%
Frequency	50Hz/60Hz
Adjusting time	＜1s (when input voltage has a change of 10%)
Efficiency	＞90%
Over-voltage protection	246V±4V
Ambient temperature	-5℃～+40℃
Relative humidity	≤90%
Waveform distoriton	No additional waveform distortion
Load power factor	0.8
Dielectric strength	1500/min
lnsulation resistance	≥2MΩ

Gallery

Meba Tested Automatic Voltage Regulator SVC-U1000VA

PDF Download

[Download not found] SVC-U1KVA Tested Automatic Voltage Regulator suit for office equipment, test equipment, medical equipment, industrial automation equipment, household lighting system, communication system, etc.

Tags Automatic Voltage Regulator, Power Regulator

Miniature Circuit Breaker

Meba mcb types MB53

Meba mcb types MB53

Specification

Application:

Meba mcb types MB53 major export to South America, Middle East market, has light weight, small size, novel structure and excellent performance. They are mounted in the metal distribution board and used in guesthouses. block of fiats, high buildings, squares, airports, railway stations, plants and enterprises etc, in AC circuits 240V(single pole)up to 415V(3poie)50Hz for protection of overload short circuit and for circuit changeover in lighting system. Breaking capacity is 3KA. The items comply with BS&NEMA STANDARD.

Technical Data

ropicalization	Relative Humidity	℃	93% RH at 25℃
ropicalization	Room Temperature	℃	10℃ a 60℃
Electrical Properties	Rated at 40℃	A	6/10/15/20/30/40/50/63
	Rated operating voltage at 40℃	Vac	120/240/415
	Nominal Frequency	Hz	50/60
	Interrupting Capacity at 230V	kA	3
	Operating temperature	℃	-5℃ a +40℃
	Degree of Protection		IP20
	Number of poles		1,2,3,4
	Conductor cross section (minimum allowable)	mm²	25
	Minimum number of power moves		4000
	Minimum number of mechanical operations		6000
	Operation curve		B/C/D
	Current Trip Curve	A	Type B 3a 5 In Type C 5 a 10 In Type D 10 a 14 In
	Characteristic Intervention		attach
Type Of Assembly	NEMA Type
Features	MAGNETIC COIL: ensures the switching of short-circuit, speaking within the following ranges: 5 to 10 times rated current (Type C), 10 to 14 times rated current ( Type D )
	BIMETAL: ensures the breaker trip when overloaded.
	ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Features

BIMETAL: ensures the breaker trip when overloaded.

ARC CHAMBER: effectively dissipates the electric arc that is generated by the opening contacts of the trigger mechanism in the presence of an overload or short circuit.

Gallery

Meba mcb types MB53

PDF Download

Tags Circuit breaker, MCB, mcb types

TND Type AC Automatic Voltage Regulator

Meba AC Automatic Voltage Regulator TND-5KVA

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba AC Automatic Voltage Regulator TND-5KVA

Meba AC Automatic Voltage Regulator TND-5KVA

Specification

General:

TND and TNS series single-phase and three-phase voltage stabilizer is developed on the basis of SVC, it not only bears all characteristics of SVC, but also has advantages of elegant appearance, luxury, economical and practical etc.

Application:

Technical Parameter

Performance:

lnput voltage	Single phase 160V~250V Three phase 277V~430V(three phase four wire)
Output voltage	Single phase 220V or 110V Three phase line voltage 380V, phase voltage 220V
Accuracy of voltage stabilization	220V±3% 110V±6%
Frequency	50Hz/60Hz
Adjusting time	＜1s (when input voltage has a change of 10%)
Efficiency	＞90%
Over-voltage protection	246V±4V
Ambient temperature	-5℃～+40℃
Relative humidity	≤90%
Waveform distoriton	No additional waveform distortion
Load power factor	0.8
Dielectric strength	1500/min
lnsulation resistance	≥2MΩ

Model and Specification:

Phase	Model	Dimension	Packing	QTY
	(kVA)	(LWH)	(LWH)
		(mm)	(mm)
Single Phase	TND-0.5	220×120×150	340×290×410	4
	TND-1	240×140×170	380×310×450	4
	TND-1.5	240×140×170	380×310×450	4
	TND-2	260×180×200	320×230×260	1
	TND-3	320×190×230	370×230×300	1
	TND-5	380×220×300	450×300×370	1
	TND-7	380×220×330	450×300×370	1
	TND-8	400×240×330	480×320×410	1
	TND-10	400×240×330	680×320×410	1
	TND-15	400×330×650	480×450×900	1
	TND-20	400×330×650	480×450×900	1
	TND-30	580×350×680	680×480×900	1
	TND-45	530×430×1020	640×530×1120	1
	TND-60	790×430×1290	900×650×1400	1
	TND-80	790×430×1290	900×650×1400	1
Three phase	TNS-1.5	400×360×170	520×480×280	1
	TNS-3	420×380×190	540×500×310	1
	TNS-4.5	420×380×190	540×500×310	1
	TNS-6	370×280×690	480×400×780	1
	TNS-9	350×330×780	480×450×900	1
	TNS-15	400×370×710	520×480×800	1
	TNS-20	460×430×790	600×550×890	1
	TNS-30	460×430×790	600×550×890	1
	TNS-45	650×430×950	780×550×1100	1
	TNS-60	650×430×950	780×550×1100	1

Gallery

Meba AC Automatic Voltage Regulator TND-5KVA

PDF Download

[Download not found] TND-5KVA AC Automatic Voltage Regulator suit for office equipment, test equipment, medical equipment, industrial automation equipment, household lighting system, communication system, etc.

Tags AC Voltage Stabilizer, superior voltage regulator

TND Type AC Automatic Voltage Regulator

Meba AC Voltage Stabilizer TND-2KVA

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba AC Voltage Stabilizer TND-2KVA

Meba AC Voltage Stabilizer TND-2KVA

Specification

General:

Application:

Technical Parameter

Performance:

lnput voltage	Single phase 160V~250V Three phase 277V~430V(three phase four wire)
Output voltage	Single phase 220V or 110V Three phase line voltage 380V, phase voltage 220V
Accuracy of voltage stabilization	220V±3% 110V±6%
Frequency	50Hz/60Hz
Adjusting time	＜1s (when input voltage has a change of 10%)
Efficiency	＞90%
Over-voltage protection	246V±4V
Ambient temperature	-5℃～+40℃
Relative humidity	≤90%
Waveform distoriton	No additional waveform distortion
Load power factor	0.8
Dielectric strength	1500/min
lnsulation resistance	≥2MΩ

Model and Specification:

Phase	Model	Dimension	Packing	QTY
	(kVA)	(LWH)	(LWH)
		(mm)	(mm)
Single Phase	TND-0.5	220×120×150	340×290×410	4
	TND-1	240×140×170	380×310×450	4
	TND-1.5	240×140×170	380×310×450	4
	TND-2	260×180×200	320×230×260	1
	TND-3	320×190×230	370×230×300	1
	TND-5	380×220×300	450×300×370	1
	TND-7	380×220×330	450×300×370	1
	TND-8	400×240×330	480×320×410	1
	TND-10	400×240×330	680×320×410	1
	TND-15	400×330×650	480×450×900	1
	TND-20	400×330×650	480×450×900	1
	TND-30	580×350×680	680×480×900	1
	TND-45	530×430×1020	640×530×1120	1
	TND-60	790×430×1290	900×650×1400	1
	TND-80	790×430×1290	900×650×1400	1
Three phase	TNS-1.5	400×360×170	520×480×280	1
	TNS-3	420×380×190	540×500×310	1
	TNS-4.5	420×380×190	540×500×310	1
	TNS-6	370×280×690	480×400×780	1
	TNS-9	350×330×780	480×450×900	1
	TNS-15	400×370×710	520×480×800	1
	TNS-20	460×430×790	600×550×890	1
	TNS-30	460×430×790	600×550×890	1
	TNS-45	650×430×950	780×550×1100	1
	TNS-60	650×430×950	780×550×1100	1

Gallery

Meba AC Voltage Stabilizer TND-2KVA

PDF Download

[Download not found] TND-2KVA AC Voltage Stabilizer suit for office equipment, test equipment, medical equipment, industrial automation equipment, household lighting system, communication system, etc.

Tags AC Voltage Stabilizer, superior voltage regulator

TND Type AC Automatic Voltage Regulator

Meba AC Voltage Stabilizer TND-500VA

Post author By meba_admin
Post date 03/01/2014
No Comments on Meba AC Voltage Stabilizer TND-500VA

Meba AC Voltage Stabilizer TND-500VA

Specification

General:

Application:

Technical Parameter

Performance:

lnput voltage	Single phase 160V~250V Three phase 277V~430V(three phase four wire)
Output voltage	Single phase 220V or 110V Three phase line voltage 380V, phase voltage 220V
Accuracy of voltage stabilization	220V±3% 110V±6%
Frequency	50Hz/60Hz
Adjusting time	＜1s (when input voltage has a change of 10%)
Efficiency	＞90%
Over-voltage protection	246V±4V
Ambient temperature	-5℃～+40℃
Relative humidity	≤90%
Waveform distoriton	No additional waveform distortion
Load power factor	0.8
Dielectric strength	1500/min
lnsulation resistance	≥2MΩ

Model and Specification:

Phase	Model	Dimension	Packing	QTY
	(kVA)	(LWH)	(LWH)
		(mm)	(mm)
Single Phase	TND-0.5	220×120×150	340×290×410	4
	TND-1	240×140×170	380×310×450	4
	TND-1.5	240×140×170	380×310×450	4
	TND-2	260×180×200	320×230×260	1
	TND-3	320×190×230	370×230×300	1
	TND-5	380×220×300	450×300×370	1
	TND-7	380×220×330	450×300×370	1
	TND-8	400×240×330	480×320×410	1
	TND-10	400×240×330	680×320×410	1
	TND-15	400×330×650	480×450×900	1
	TND-20	400×330×650	480×450×900	1
	TND-30	580×350×680	680×480×900	1
	TND-45	530×430×1020	640×530×1120	1
	TND-60	790×430×1290	900×650×1400	1
	TND-80	790×430×1290	900×650×1400	1
Three phase	TNS-1.5	400×360×170	520×480×280	1
	TNS-3	420×380×190	540×500×310	1
	TNS-4.5	420×380×190	540×500×310	1
	TNS-6	370×280×690	480×400×780	1
	TNS-9	350×330×780	480×450×900	1
	TNS-15	400×370×710	520×480×800	1
	TNS-20	460×430×790	600×550×890	1
	TNS-30	460×430×790	600×550×890	1
	TNS-45	650×430×950	780×550×1100	1
	TNS-60	650×430×950	780×550×1100	1

Gallery

Meba AC Voltage Stabilizer TND-500VA

PDF Download

[Download not found] TND-0.5KVA AC Voltage Stabilizer suit for office equipment, test equipment, medical equipment, industrial automation equipment, household lighting system, communication system, etc.

Tags AC Voltage Stabilizer, superior voltage regulator
