Pkastic Terminals:
Terminal Blocks U(W) type;
Matcrial: made from PA, PE or PP.
Material Difference:
1) PE, Polyethylene, good pliability, transparence, extensibility ,resist dissolve, radiation. Working TemperatureL-40°C-65°C；
Brass, scrcw is lron plated zinc;
Voltage:250-450V;
Color:Natural color as standard.
2) PP, PloyPropylene, inflamiing retauling, low transparency, low rigidity, goodbounce impactforcc. Working Tcmpcraturc:-20°C~90°C；
Brass, screw is lron plated zinc;
Voltage:250~450V;
Color:Natural color as standard.
3) PA, Polyamide 66, 94V-2grade. Inflaming ratarding, good resist dissolve, goodbounce;
Impact force, Working TemeratureL-30°C-110°C;
Brass, screw is lron plated zinc;
Voltagc:250-450V;
Color: Natural color as standard.
All products that we supplied have the feature of safety, reliable, convenient and cheaper in price. Good in power conductor, lower in contact resistance, full range of specification. Customer satisfaction is our greatest pursuit !
| ITEM.NO. | L | W | H | mm² | VOLT | AMP | Code |
| H-3A | 91 | 17 | 12 | 4 | 380V | 3A | D010 |
| H-6A | 106 | 15.5 | 13.5 | 6 | 380V | 6A | D011 |
| H-10A | 126 | 21 | 15 | 10 | 380V | 10A | D021 |
| H-16A | 133 | 21.3 | 16 | 12 | 380V | 16A | D022 |
| H-20A | 140 | 22 | 16 | 14 | 380V | 20A | D014 |
| H-30A | 164 | 24 | 20 | 20 | 380V | 30A | D023 |
| H-60A | 189 | 30 | 25 | 25 | 380V | 60A | D025 |
| H-80A | 205 | 35 | 28 | 35 | 380V | 80A | D026 |
| H-100A | 233 | 40 | 30 | 40 | 380V | 100A | D027 |
| H-150A | 255 | 45 | 35 | 60 | 380V | 150A | D028 |
Packing Unit:
| H(W) TYPE | PCS/BAG | PCS/CTN | MEAST(CM) | G.W.(KG) | N.W.(KG) |
| 3A | 10 | 1200 | 41*19*31 | 18 | 17 |
| 5A | 10 | 1200 | 47*22*28.5 | 20.5 | 19.5 |
| 10A | 10 | 500 | 53*26*16.2 | 16 | 15 |
| 16A | 10 | 500 | 56.5*28*18.5 | 19 | 18 |
| 20A | 10 | 500 | 56.5*28*18.5 | 20 | 19 |
| 30A | 10 | 300 | 50.5*25.5*20 | 18 | 17 |
| 60A | 10 | 200 | 39*32*28 | 21 | 20 |
| 80A | 10 | 120 | 34.5*21.5*35 | 21.5 | 20.5 |
| 100A | 10 | 100 | 39*24*32.5 | 22.5 | 21.5 |
| 150A | 10 | 50 | 37*26.5*23.5 | 20 | 19 |
Meba Polyamide Screw Connector Terminal Block Connector MBT383 feature of safety, reliable, convenient and cheaper in price. Good in power conductor, lower in contact resistance, full range of specification.
