Meba Hall Sensor SM8

meba hall sensor sm8

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Briefintroduction:

SM series Hall sensor is a kind of magnet sensitive sensor consisting of voltage regulator, Hall voltage generator, differential amplifier Schmidt trigger and the output pole of collector open circuit. Its input is the magnetic flux density. The output is a digital voltage signal.

Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Hall Sensor SM8):

Outward appearance code: SM8
Detection distance: 10mm
Power voltage: 5~24VDC
Detectable object: Permanent magnet
Output low level voltage: 200mV
Output high level voltage: 0.1uA
Power current: 8mA
ON-OFF frequency: 320KHz
Working point magnetic density: 22mT
Shell material: Metal
Ambient temperature: -25°C~70°C
Protection grade: IEC standard IP67
Model avalibale                                         NPN NO SM8-31010NA
PNP NO SM8-31010PA
NPN NC —
PNP NC —
Categories
Circuit Breaker

LW 630S C Series Moulded Case Circuit Breaker

moulded casw circuit breaker
Categories
Proximity Switch

Meba 5mm Detection Distance Proximity Switch LMF11

meba 5mm detection distance proximity switch lmf11

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(5mm Detection Distance Proximity Switch):

Model NO. Detection distance Working voltage Output Flush
Form State
LMF11-3005NA 5mm DC6-36V NPN NO Flush
LMF11-3005NB 5mm DC6-36V NPN NC Flush
LMF11-3005NC 5mm DC6-36V NPN NO+NC Flush
LMF11-3005PA 5mm DC6-36V PNP NO Flush
LMF11-3005PB 5mm DC6-36V PNP NC Flush
LMF11 -3005PC 5mm DC6-36V PNP NO+NC Flush
LMF11 -3005LA 5mm AC90-250V Two wire system NO Flush
LMF11-3005LB 5mm AC90-250V Two wire system NC Flush
Categories
Proximity Switch

Meba 12vdc Proximity Switch With Straight Connector LMF10

meba 12vdc proximity switch with straight connector lmf10

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(12vdc Proximity Switch With Straight Connector LMF10):

Model NO. Detection distance Detection distance Output Flush
Form State
LMF10-3015NA 15mm DC6-36V NPN NO Flush
LMF10-3015NB 15mm DC6-36V NPN NC Flush
LMF10-3015NC 15mm DC6-36V NPN NO+NC Flush
LMF10-3015PA 15mm DC6-36V PNP NO Flush
LMF10-3015PB 15mm DC6-36V PNP NC Flush
LMF10-3015PC 15mm DC6-36V PNP NO+NC Flush
LMF10-3015LA 15mm DC6-36V Two wire system NO Flush
LMF10 -3015LB 15mm DC6-36V Two wire system NC Flush
LMF10 -2015A 15mm AC90-250V SCR control
lable silicon		 NO Flush
LMF10-2015B 15mm AC90-250V SCR control
lable silicon		 NC Flush
LMF10 -2015C 15mm AC90-250V SCR control
lable silicon		 NO+NC Flush
LMF10-3020NA 20mm DC6-36V NPN NO Non-flush
LMF10-3020NB 20mm DC6-36V NPN NC Non-flush
LMF10-3020NC 20mm DC6-36V NPN NO+NC Non-flush
LMF10-3020PA 20mm DC6-36V PNP NO Non-flush
LMF10-3020PB 20mm DC6-36V PNP NC Non-flush
LMF10-3020PC 20mm DC6-36V PNP NO+NC Non-flush
LMF10-3020LA 20mm DC6-36V Two wire system NO Non-flush
LMF10 -3020LB 20mm DC6-36V Two wire system NC Non-flush
LMF10 -2020A 20mm AC90-250V SCR control
lable silicon		 NO Non-flush
LMF10-2020B 20mm AC90-250V SCR control
lable silicon		 NC Non-flush
LMF10 -2020C 20mm AC90-250V SCR control
lable silicon		 NO+NC Non-flush
Categories
Proximity Switch

Meba Proximity Sensor LMF7

meba proximity sensor lmf7

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter:

1

Model NO. Detection distance Working voltage Output Flush
Form State
LMF7-30010NA 10mm DC6-36V NPN NO Flush
LMF7-3010NB 10mm DC6-36V NPN NC Flush
LMF7-3010PA 10mm DC6-36V NPN NO Flush
LMF7-3010PB 10mm DC6-36V PNP NC Flush
LMF7-3010LA 10mm DC6-36V Two wire system N0 Flush
LMF7 -3010LB 10mm DC6-36V Two wire system NC Flush
LMF7 -20010A 10mm AC90-250V SCR control lable silicon NO Flush
LMF7 -2010B 10mm AC90-250V SCR control lable silicon NC Flush
LMF7 -2010C 10mm AC90-250V SCR control lable silicon NO+NC Flush
LMF7-3015NA 15mm DC6-36V NPN NO Non-Flush
LMF7-3015NB 15mm DC6-36V NPN NC Non-flush
LMF7-3015NC 15mm DC6-36V NPN NO+NC Non-flush
LMF7-3015PA 15mm DC6-36V PNP NO Non-flush
LMF7-3015PB 15mm DC6-36V PNP NC Non-flush
LMF7-3015PC 15mm DC6-36V PNP NO+NC Non-flush
LMF7 -3015LA 15mm DC6-36V Two wire system NO Non-flush
LMF7 -3015LB 15mm DC6-36V Two wire system NC Non-flush
LMF7 -2015A 15mm DC6-36V SCR control lable silicon NO Non-flush
LMF7 -2015B 15mm AC90-250V SCR control lable silicon NC Non-flush
LMF7 -2015C 15mm AC90-250V SCR control lable silicon NO+NC Non-flush
Categories
Proximity Switch

Meba Proximity Switch LMF6

meba proximity switch lmf6

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter:

Model NO. Detection distance Working voltage Output Flush
Form State
LMF6-3008NA 8mm DC6-36V NPN NO Flush
LMF6-3008NB 8mm DC6-36V NPN NC Flush
LMF6-3008NC 8mm DC6-36V NPN NO+NC Flush
LMF6-3008PA 8mm DC6-36V PNP NO Flush
LMF6-3008PB 8mm DC6-36V PNP NC Flush
LMF6-3008PC 8mm DC6-36V PNP NO+NC Flush
LMF6-3008LA 8mm DC6-36V Two wire system NO Flush
LMF6 -3008LB 8mm DC6-36V Two wire system NC Flush
LMF6 -2008A 8mm AC90-250V SCR control lable silicon NO Flush
LMF6-2008B 8mm AC90-250V SCR control lable silicon NC Flush
LMF6-3010NA 10mm DC6-36V NPN NO Non-flush
LMF6-3010NB 10mm DC6-36V NPN NO Non-flush
LMF6-3010NC 10mm DC6-36V NPN NO+NC Non-flush
LMF6-3010PA 10mm DC6-36V PNP NO Non-flush
LMF6-3010PB 10mm DC6-36V PNP NC Non-flush
LMF6-3010PC 10mm DC6-36V PNP NO+NC Non-flush
LMF6-3010PA 10mm DC6-36V Two wire system NO Non-flush
LMF6 -3010LB 10mm DC6-36V Two wire system NC Non-flush
LMF6 -2010A 10mm AC90-250V SCR control lable silicon NO Non-flush
LMF6-2010B 10mm AC90-250V SCR control lable silicon NC Non-flush
Categories
Proximity Switch

Meba Cylinder Series Proximity Pwitch LMF4

meba cylinder series proximity switch lmf4

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Cylinder Series Proximity Pwitch LMF4):

Model NO. Detection distance Working voltage Output Flush
Form State
LMF4-3005NA 5mm DC6-36V NPN NO Flush
LMF4-3005NB 5mm DC6-36V NPN NC Flush
LMF4-3005NC 5mm DC6-36V NPN NO+NC Flush
LMF4-3005PA 5mm DC6-36V PNP NO Flush
LMF4-3005PB 5mm DC6-36V PNP NC Flush
LMF4 -3005PC 5mm DC6-36V PNP NO+NC Flush
LMF4 -3005LA 5mm AC90-250V Two wire system NO Flush
LMF4-3005LB 5mm AC90-250V Two wire system NC Flush
Categories
Proximity Switch

Meba Corner Column Type Proximity Sensor LMF3

meba corner column type proximity sensor lmf3

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Corner Column Type Proximity Sensor LMF3):

Model NO. Detection distance Working voltage Output Flush
Form State
LMF3-3005NA 5mm DC6-36V NPN NO Flush
LMF3-3005NB 5mm DC6-36V NPN NC Flush
LMF3-3005PA 5mm DC6-36V PNP NO Flush
LMF3-3005PB 5mm DC6-36V PNP NC Flush
LMF3-3005LA 5mm DC6-36V Two wire system NO Flush
LMF3 -3005LB 5mm DC6-36V Two wire system NC Flush
LMF3 -2005A 5mm AC90-250V SCR control lable silicon NO Non-flush
LMF3-2005B 5mm AC90-250V SCR control lable silicon NC Non-flush
Categories
Float Switch

Meba Water Level Float Switch M15-1B

meba water level float switch M15-1B

Specification

Introduction:

1. Cable Float Switch uses one-step shaping injection molding with substantial structure, cheap price and long lifetime.

2. It has very good control effect for long distance, multiple level control, submerged pump or liquid with grain or block.Certainly it is also useful for normal liquid.

3. It uses Micro Switch to make connection output. Connection point capacity 10A/250VAC can start the motor equipment directly.

4. It can be regulated freely and easy to operate, convenient to install, safe and reliable, without maintenance, non-toxic and environment friendly.

5. It can resist sewage so that widely used in pool in resident, factories and mines ect., and ponds, barrel, manger and pot with oil, acid and alkali as well as the vessel with high viscosity and suspended substance.

Feature:

• Low cost level switch made from Polypropylene

• Hermetically sealed double chamber construction

• Mercury-free micro switch

• Direct pump-control operation up to 1.1 KW,

• without external contactor

• Adjustable switch diff erential

• Switch rating 250 V AC –10A

• Temperature 200 C to 800 C

• Pressure MAX. 5 bar

• Protection IP68

Technical Parameter:

Product Name water level float switch
Electrical rate 250V/4A
Contact Mode SPDT, NO, NC
Working Temperature 0~60°C(PVC cable), 0~80°C(Rubber cable)
Protection grade IP 68
Float Material PP/PVC
Application water, sewage, acid-bases liquid
Working Pressure ±0.5Mpa
CableMaterial PVC/rubber
Length 5m(standard); length could be customized
Conductor size 3×0.5m㎡ (standard);3*0.75m㎡,3*1m㎡



Working Environment:

Rated voltage 250V (380V)
Rated current 10A (3A)
Working temperature 0°C to 80°C
Mechanical endurance ≥100,000times
Electrical endurance ≥50,000times
Protection setting IP68CS



How they work?
As the water rises, at a pre-determined level the switch turns on the pump. Once the level has been reduced to the level you set

Automatically turns On and Off

Adjustable switching level

Plugged models are simple to install
(no electrician required)

Categories
Proximity Switch

Meba NPN Proximity Switch LMF1

meba npn proximity switch lmf1

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(NPN Proximity Switch LMF1):

Model NO. Detection distance Working voltage Output Flush
Form State
LMF1-3005NA 5mm DC6-36V NPN NO Flush
LMF1-3005NB 5mm DC6-36V NPN NC Flush
LMF1-3005PA 5mm DC6-36V PNP NO Flush
LMF1-3005PB 5mm DC6-36V PNP NC Flush
LMF1-3005LA 5mm DC6-36V Two wire system NO Flush
LMF1 -2005A 5mm AC90-250V SCR control lable silicon NO Non-flush
Categories
Proximity Switch

Meba Inductance Proximity Switch LMF2

meba inductance proximity switch lmf2

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Inductance Proximity Switch LMF2):

Model NO. Detection distance Working voltage Output Flush
Form State
LMF2-3005NA 5mm DC6-36V NPN NO Flush
LMF2-3005NB 5mm DC6-36V NPN NC Flush
LMF2-3005PA 5mm DC6-36V PNP NO Flush
LMF2-3005PB 5mm DC6-36V PNP NC Flush
LMF2-3005LA 5mm DC6-36V Two wire system NO Flush
LMF2 -2005A 5mm AC90-250V SCR control lable silicon NO Non-flush
Categories
Proximity Switch

Meba Cylider Type Inductive Proximity Sensor LM40

meba cylider type inductive proximity sensor lm40

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life



Technical Parameter(Cylider Type Inductive Proximity Sensor LM40):

Outward appearance code IM40
Overall dimensions
 Flush Detection distance
DC 10~30VDC NPN NO
NC
NO+NC
PNP NO
NC
NO+NC
two wire system NO
NC
AC 90~250 VAC SCR Control- lable silicon NO
NC
NO+NC
Relay  output
Non- Flush Detection distance 20mm
DC 10~30VDC NPN NO LM40-3020NA
NC LM40-3020NB
NO+NC LM40-3020NC
PNP NO LM40-3020PA
NC LM40-3020PB
NO+NC LM40-3020PC
two wire system NO LM40-3020LA
NC LM40-3020LB
AC 90~250 VAC SCR  Control- lable silicon NO LM40-2020A
NC LM40-2020B
NO+NC LM40-2020C
Relay  output LM40-2020JC
Output current DC ≤200mA
SCR/ Relay ≤300mA/1A
Output voltage dropDC/AC

DC/AC  below 3V/ 10V

two wire below 3.9V
Consumption current  AC 10mA,  DC<15mA
Standard detected object 45×45×1（A3 iron）
Repeated precision 0.1
DC/AC Response frequency 100Hz/10Hz
Working environment temperature -25℃~+75℃
Insulation resistance ≥50MΩ
Shell material Metal
Protection grade IP67
Altemative model at home and abroad SC-□□
Current short-circuit protecion 200mA
Categories
Proximity Switch

Meba Angular Column Type Proximity Switch LMF370

meba angular column type proximity switch lmf370

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Angular Column Type Proximity Switch LMF370):

Model NO. Detection distance Working voltage Output Flush
Form State
LMF370-3040NA 40mm DC6-36V NPN NO Non-flush
LMF370-3040NB 40mm DC6-36V NPN NC Non-flush
LMF370-3040NC 40mm DC6-36V NPN NO+NC Non-flush
LMF370-3040PA 40mm DC6-36V PNP NO Non-flush
LMF370-3040PB 40mm DC6-36V PNP NC Non-flush
LMF370-3040PC 40mm DC6-36V PNP NO+NC Non-flush
LMF370-3040LA 40mm DC6-36V Two wire system NO Non-flush
LMF370 -3040LB 40mm DC6-36V Two wire system NC Non-flush
LMF370 -2040A 40mm AC90-250V SCR Control label silicon NO Non-flush
LMF370-2040B 40mm AC90-250V SCR Control label silicon NC Non-flush
Categories
Proximity Switch

Meba Connector Type Sensor LM30-T

meba connector type sensor lm30-t

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Connector Type Sensor LM30-T):

Model NO. Detection distance Working voltage Output Flush
Form State
LM30-3010NAT 10mm DC6-36V NPN NO Flush
LM30-3010NBT 10mm DC6-36V NPN NC Flush
LM30-3010NCT 10mm DC6-36V NPN NO+NC Flush
LM30-3010PAT 10mm DC6-36V PNP NO Flush
LM30-3010PBT 10mm DC6-36V PNP NC Flush
LM30-3010PCT 10mm DC6-36V PNP NO+NC Flush
LM30-3010LAT 10mm DC6-36V Two wire system NO Flush
LM30-3010LBT 10mm DC6-36V Two wire system NC Flush
LM30-2010AT 10mm AC90-250V SCR Control label silicon NO Flush
LM30-2010BT 10mm AC90-250V SCR Control label silicon NC Flush
LM30-3015NAT 15mm DC6-36V NPN NO Non-flush
LM30-3015NBT 15mm DC6-36V NPN NC Non-flush
LM30-3015NCT 15mm DC6-36V NPN NO+NC Non-flush
LM30-3015PAT 15mm DC6-36V PNP NO Non-flush
LM30-3015PBT 15mm DC6-36V PNP NC Non-flush
LM30-3015PCT 15mm DC6-36V PNP NO+NC Non-flush
LM30-3015LAT 15mm DC6-36V Two wire system NO Non-flush
LM30-3015LBT 15mm DC6-36V Two wire system NC Non-flush
LM30-2015AT 15mm AC90-250V SCR Control label silicon No Non-flush
LM30-2015BT 15mm AC90-250V SCR Control label silicon NC Non-flush
Categories
Proximity Switch

Meba Inductive Proximity Sensor Connector LM30-T3

meba inductive proximity sensor connector lm30-t3

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Inductive Proximity Sensor  LM30-T3):

Model NO. Detection distance Working voltage Output Flush
Form State
LM30-3010NAT3 10mm DC6-36V NPN NO Flush
LM30-3010NBT3 10mm DC6-36V NPN NC Flush
LM30-3010NCT3 10mm DC6-36V NPN NO+NC Flush
LM30-3010PAT3 10mm DC6-36V PNP NO Flush
LM30-3010PBT3 10mm DC6-36V PNP NC Flush
LM30-3010PCT3 10mm DC6-36V PNP NO+NC Flush
LM30-3010LAT3 10mm DC6-36V Two wire system NO Flush
LM30-3010LBT3 10mm DC6-36V Two wire system NC Flush
LM30-2010AT3 10mm AC90-250V SCR Control label silicon NO Flush
LM30-2010BT3 10mm AC90-250V SCR Control label silicon NC Flush
LM30-3015NAT3 15mm DC6-36V NPN NO Non-flush
LM30-3015NBT3 15mm DC6-36V NPN NC Non-flush
LM30-3015NCT3 15mm DC6-36V NPN NO+NC Non-flush
LM30-3015PAT3 15mm DC6-36V PNP NO Non-flush
LM30-3015PBT3 15mm DC6-36V PNP NC Non-flush
LM30-3015PCT3 15mm DC6-36V PNP NO+NC Non-flush
LM30-3015LAT3 15mm DC6-36V Two wire system NO Non-flush
LM30-3015LBT3 15mm DC6-36V Two wire system NC Non-flush
LM30-2015AT3 15mm AC90-250V SCR Control label silicon No Non-flush
LM30-2015BT3 15mm AC90-250V SCR Control label silicon NC Non-flush
Categories
Proximity Switch

Meba Straight Connector LM22-T3

meba straight connector lm22-t3

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Straight Connector LM22-T3):

Outward appearance code LM22-口口T3








Flush

 Detection distance 7m


DC

6-36

VDC

 NPN NO LM22-3007NAT3
NC LM22-3007NBT3
NO+NC LM22-3007NCT3
PNP NO LM22-3007PAT3
NC LM22-3007PBT3
NO+NC LM22-3007PBT3
Two wiresysterm NO LM22-3007LAT3
NC LM22-3007LBT3
AC90~250

VAC

 SCR control-lable silicon NO LM22-2007AT3
NC LM22-2007BT3
NO+NC
Relay output












Non-

flush

 Detection distance 10mm


DC

6-36

VDC

 NPN NO LM22-3010NAT3
NC LM22-3010NBT3
NO+NC LM22-3010NCT3
PNP NO LM22-3010PAT3
NC LM22-3010PBT3
NO+NC LM22-3010PCT3
Twowire system NO LM22-3010LAT3
NC LM22-3010LBT3
AC90~250

VAC

 SCR Control-lablesilicon NO LM22-2010AT3
NC LM22-2010BT3
NO+NC
Relay output
Output current DC 200mA
SCR/ Relay 300mA
Output voltage drop DC/AC DC＜3V, AC＜10V,  DC two wire＜3.9V
Consumption current DC12V＜8mA,  DC24V＜8mA,  AC＜10mA
Standard detected object 18*18*1 A3 Iron
Repeated precision 0.05
DC/AC Response frequency 200Hz/10Hz
Working environment temperature -25°C~+65°C
Insulation resistance 50MΩ
Shell material Metal
Protection grade IP67
Altemative model at home and abroad ——
Categories
Proximity Switch

Meba 22mm Diameter With Connector Inductive Sensor LM22-T

meba 22mm diameter with connector inductive sensor lm22-t

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Connector Inductive Sensor LM22-T):

Outward appearance code LM22-口口T
Flush Detection distance 7mm
DC

6-36

VDC

 NPN NO LM22-3007NAT
NC LM22-3007NBT
NO+NC LM22-3007NCT
PNP NO LM22-3007PAT
NC LM22-3007PBT
NO+NC LM22-3007PBT
Two wiresysterm NO LM22-3007LAT
NC LM22-3007LBT
AC

90~250

VAC

 SCR control-lable silicon NO LM22-2007AT
NC LM22-2007BT
NO+NC
Relay output
Non-flush Detection distance 10mm


DC

6-36

VDC

 NPN NO LM22-3010NAT
NC LM22-3010NBT
NO+NC LM22-3010NCT
PNP NO LM22-3010PAT
NC LM22-3010PBT
NO+NC LM22-3010PCT
Twowire system NO LM22-3010LAT
NC LM22-3010LBT
AC

90~250

VAC

 SCR Control-lablesilicon NO LM22-2010AT
NC LM22-2010BT
NO+NC
Relay output
Output current DC 200mA
SCR/ Relay 300mA
Output voltage drop DC/AC DC＜3V, AC＜10V,  DC two wire＜3.9V
Consumption current DC12V＜8mA,  DC24V＜8mA,  AC＜10mA
Standard detected object 18*18*1 A3 Iron
Repeated precision 0.0036
DC/AC Response frequency 200Hz/10Hz
Working environment temperature -25°C~+65°C
Insulation resistance 50MΩ
Shell material Metal
Protection grade IP67
Altemative model at home and abroad —
Categories
Proximity Switch

Meba Inductive Load Switching Sensors LM18-T

meba inductive load switching sensors lm18-t

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Inductive Load Switching Sensors LM18-T):

Model NO. Detection distance Working voltage Output Flush
Form State
LM18-3005NAT 5mm DC6-36V NPN NO Flush
LM18-3005NBT 5mm DC6-36V NPN NC Flush
LM18-3005NCT 5mm DC6-36V NPN NO+NC Flush
LM18-3005PAT 5mm DC6-36V PNP NO Flush
LM18-3005PBT 5mm DC6-36V PNP NC Flush
LM18-3005PCT 5mm DC6-36V PNP NO+NC Flush
LM18-3005LAT 8mm DC6-36V Two wire system NO Flush
LM18-3005LBT 5mm DC6-36V Two wire system NC Flush
LM18-2005AT 5mm AC90-250V SCR Control label silicon NO Flush
LM18-2005BT 5mm AC90-250V SCR Control label silicon NC Flush
LM18-3008NAT 8mm DC6-36V NPN NO Non-flush
LM18-3008NBT 8mm DC6-36V NPN NC Non-flush
LM18-3008NCT 8mm DC6-36V NPN NO+NC Non-flush
LM18-3008PAT 8mm DC6-36V PNP NO Non-flush
LM18-3008PBT 8mm DC6-36V PNP NC Non-flush
LM18-3008PCT 8mm DC6-36V PNP NO+NC Non-flush
LM18-3008LAT 8mm DC6-36V Two wire system NO Non-flush
LM18-3008LBT 8mm DC6-36V Two wire system NC Non-flush
LM18-2008AT 8mm AC90-250V SCR Control label silicon NO Non-flush
LM18-2008BT 8mm AC90-250V SCR Control label silicon NC Non-flush
Categories
Proximity Switch

Meba Magnetic Proximity Switch LM18-T3

meba magnetic proximity switch lm18-t3

Specification

Model explanation of proximity switch:

Number Composition Code and Definition
1 Switch catalogue LM: inductance type; CM: capactitance type; SM:Hall type;
AM:safety explosion- proof type; XM: mimic linear type
2 Outward appearance code ■: Cylinder type;
F: Angular column type and plane installation type
3 Working voltage 30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC;
20: 90-250VAC; 210: 24-250VAC; 220: 380VAC;
40: 12-240VDC/24-240AC; 50: Special voltage
4 Detection distance 01: 1mm; 05:5mm; 10:10mm
5 Output form N: Three-line DC NPN output; P: Three-line DC PNP output;
L: Two-line DC output; ■: AC two-wire output;
J: Relay output; NP: NPN+PNP output
6 Output state A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current
7 Subsidiary functions T: With connector; Y: Water proof, oil proof;
I: Special requirement; H: High temp resistance; R: Ring type



Main features:

– Compact volume

– high precision of repeated location

– Diversified exterior structures

– Good performance of anti-interference.

– Many output forms

– High on-off frequency

– Wide voltage range

– Dust proof,vibration proof,water proof and oil proof.

– With short-circuit protection and inverted connecting protection.

– Long service life

 Technical Parameter(Magnetic Proximity Switch LM18-T3):

Model NO. Detection distance Working voltage Output Flush
Form State
LM18-3005NAT3 5mm DC6-36V NPN NO Flush
LM18-3005NBT3 5mm DC6-36V NPN NC Flush
LM18-3005NCT3 5mm DC6-36V NPN NO+NC Flush
LM18-3005PAT3 5mm DC6-36V PNP NO Flush
LM18-3005PBT3 5mm DC6-36V PNP NC Flush
LM18-3005PCT3 5mm DC6-36V PNP NO+NC Flush
LM18-3005LAT3 8mm DC6-36V Two wire system NO Flush
LM18-3005LBT3 5mm DC6-36V Two wire system NC Flush
LM18-2005AT3 5mm AC90-250V SCR Control label silicon NO Flush
LM18-2005BT3 5mm AC90-250V SCR Control label silicon NC Flush
LM18-3008NAT3 8mm DC6-36V NPN NO Non-flush
LM18-3008NBT3 8mm DC6-36V NPN NC Non-flush
LM18-3008NCT3 8mm DC6-36V NPN NO+NC Non-flush
LM18-3008PAT3 8mm DC6-36V PNP NO Non-flush
LM18-3008PBT3 8mm DC6-36V PNP NC Non-flush
LM18-3008PCT3 8mm DC6-36V PNP NO+NC Non-flush
LM18-3008LAT3 8mm DC6-36V Two wire system NO Non-flush
LM18-3008LBT3 8mm DC6-36V Two wire system NC Non-flush
LM18-2008AT3 8mm AC90-250V SCR Control label silicon NO Non-flush
LM18-2008BT3 8mm AC90-250V SCR Control label silicon NC Non-flush
